Engine loom clio 98R3T

98 Cup R3T Engine Wiring Harness

The XAP Technology 98 Cup R3T Engine Wiring Harness brings together the connections for the main engine and gearbox sensors and actuators. Designed for the 98 Cup electrical architecture, it connects the injection and ignition systems, turbo control, high-pressure pump and temperature sensors. Its clearly defined connection scope helps streamline electrical integration and vehicle preparation.

Key features

• Engine wiring harness dedicated to the 98 Cup architecture.
• Connections for injection and ignition components.
• Connections for turbo control and the high-pressure pump.
• Connections for the specified position, pressure and temperature sensors.
• XAP reference PF0025 associated with Renault reference 8201412197.

Connected equipment

• Camshaft.
• MAP and BOOST pressure sensor.
• Throttle body.
• Fuel injection rail.
• Four coils.
• Turbo solenoid valve (wastegate).
• High-pressure (HP) pump.
• Gearbox position sensor.
• Solenoid.
• Oil temperature sensor.
• Water temperature sensor.

Documentation

Technical data sheet and wiring documentation available from XAP on request.
