Chassis loom clio 98R3T

98 Cup R3T chassis wiring harness

The XAP Technology 98 Cup chassis wiring harness brings together the connections for the vehicle’s main electrical and electronic equipment. Manufactured with heat-shrink sleeving, it connects the dashboard, steering wheel, ECU, power box and data acquisition equipment. This dedicated architecture helps organise the 98 Cup wiring and provides a coherent foundation for integrating control, engine management and safety functions.

Key features

• Dedicated wiring architecture for the 98 Cup R3T.
• Manufactured with heat-shrink sleeving.
• Centralised connection of control, engine management, data acquisition and safety equipment.
• XAP reference PF0026 associated with Renault reference 8201412199.

Connected equipment

• Dashboard.
• Steering wheel.
• Electric window.
• ESP.
• Accelerator pedal.
• Button panel.
• ECU.
• Relay.
• Power box.
• Engine communication and data acquisition connector.
• GPS.
• Beacon.
• Fire extinguisher.
• Lambda.
• LP fuel pump and sensor.
• Master relay.

Documentation

Technical data sheet and wiring documentation available from XAP on request.
