FRONT HARNESS TTM 2018

Laméra cup Front Wiring Harness

This wiring harness is custom-designed for the Laméra cup. It gathers the connections required by the main equipment located at the front of the vehicle, simplifying their wiring within an architecture dedicated to this car.

Key Points

• Custom design for the Laméra cup.
• Connection of the brake pressures.
• Connection of the heated windscreen.
• Connection of the cooling fan.
• Connection of the headlights.
• Connection of the fuel pumps.
• Connection of the windscreen wipers.
• Integration of the safety switch.
• XAP reference PF0552.

Connected Equipment

• Brake pressures.
• Heated windscreen.
• Cooling fan.
• Headlights.
• Fuel pumps.
• Windscreen wipers.
• Safety switch.

Documentation

Technical datasheet and wiring documentation available on request from XAP.
