Laméra POWER HARNESS FUSE BOX

Laméra Power Harness

This power wiring harness is dedicated to the Laméra. It groups the connections required to power and wire the main electrical equipment of the vehicle, simplifying their installation within an architecture designed for this car.

Key Points

• Power harness designed for the Laméra.
• Connection of the RTCM.
• Connection of the fan.
• Connection of the power steering.
• Connection of the master switch.
• XAP reference PF0553.

Connected Equipment

• RTCM.
• Fan.
• Power steering.
• Master switch.

Documentation

Technical datasheet and wiring documentation available on request from XAP.
