Engine loom Laméra 4 cylinder part 1/2
Inscrivez-vous/connectez-vous pour voir nos tarifs
Laméra 4-Cylinder Engine Interface Harness
This interface harness is designed for the Laméra 4-cylinder engine. It provides the link between the engine control unit and the GDI (gasoline direct injection) module, then connects the cockpit and the engine bay through two dedicated bulkhead pass-through connectors. XAP offers this harness to centralise the engine-bay wiring and simplify the connection of the cockpit and engine looms within a consistent architecture.
Key points
- Design dedicated to the Laméra 4-cylinder engine.
- Connection of the engine control unit.
- Connection of the GDI (gasoline direct injection) module.
- Bulkhead pass-through link to the cockpit loom.
- Bulkhead pass-through link to the engine loom.
- XAP reference PF0938.
Connected equipment
- Engine control unit.
- GDI (gasoline direct injection) module.
- Bulkhead pass-through connector to cockpit loom.
- Bulkhead pass-through connector to engine loom.
| Reference | Description |
|---|---|
| PF0938 | Laméra 4-cylinder engine interface harness |
Documentation
Technical data sheet and wiring documentation available on request from XAP.
PF0938
