Chassis loom Laméra

Laméra cockpit harness

This wiring harness is designed for the Laméra cockpit. It groups the connections required for the main equipment located in the cockpit and provides the transition to the engine bay and the rear harness, simplifying the integration of the vehicle's electrical architecture.

Key points

• Cockpit harness dedicated to the Laméra.
• Connection of the RTCM module.
• Connection of the ESHIFT system.
• Connection of the Dash NT5 and the steering wheel.
• Connection of the radio and the heated windscreen.
• Connection of the master relay and the accelerator pedal.
• Engine bulkhead passthrough and link to the rear harness.
• XAP reference PF0554.

Connected equipment

• RTCM.
• ESHIFT.
• Engine bulkhead passthrough.
• Dash NT5.
• Steering wheel.
• Radio.
• Heated windscreen.
• Master relay.
• Accelerator pedal.
• Passthrough to the rear harness.

Documentation

Technical datasheet and wiring documentation available on request from XAP.
