E-SHIFT-110+POWERBOX-110

E-Shift 1 + Powerbox Kit – XAP's Complete Electric Sequential Gearbox Control Solution

The XAP E-Shift 1 + Powerbox Kit combines the E-Shift 1 electromagnetic actuator with its dedicated electronic control module to provide an integrated solution for electric sequential gearbox actuation.

It is designed for motorsport applications requiring fast gear changes, reliability and reduced system complexity compared with conventional pneumatic or hydraulic solutions.

High-performance electromagnetic Push/Pull actuator

At the heart of the system, the E-Shift 1 uses moving-magnet technology combined with an internal magnetic spring.

It provides ±18 mm stroke, up to 500 N starting pushing force and up to 200 N middle pushing force, with a peak current of 30 A. Supply voltage ranges from 9 to 18 V.

Powerbox: dedicated system control electronics

The Powerbox complements the actuator and enables its integration into the vehicle's electrical and electronic architecture.

The E-Shift 1 system supports CAN control as well as dedicated CMD_UP and CMD_DOWN wired commands. CAN diagnostics are also available.

Together, these components provide a solution suited to modern racing vehicle architectures.

Fewer components and reduced maintenance

Unlike pneumatic or hydraulic architectures, the E-Shift electromagnetic system does not require a pump, fluid circuit, tubing or the associated seals.

This simplified architecture reduces the number of components required for installation and minimizes maintenance requirements.

A complete XAP solution

Combining the E-Shift 1 actuator and Powerbox provides an integrated system developed around a common architecture for electric sequential gearbox control.

The result is a fast, reliable solution engineered for modern motorsport and backed by XAP's experience in electromagnetic sequential gearbox actuators.
